P+F detection type sensor UB400-12GM-I-V1
BWP 00265
B 17
Cart Mobile
Detection range 30 mm - 400 mm
Blind zone: 0 mm - 30 mm
Setting range 50 mm - 400 mm
Standard plate 100 mm x 100 mm
Converter frequency: Approx. 310 kHz
Response delay: Approx. 50 ms
Red LED: Permanently red: Malfunction, flashing red: Learning function, object not detected
No-load current ≤ 30 mA
Storage temperature: -40 °C to +85 °C.
Resolution 0.17 mm
Reproducibility: ± 0.5% of the final value
Converter: Epoxy resin/glass-shout ball mixture, foam polyurethane, cover PBT
Weight 25 g
Characteristic deviation: ± 1% from the end value
Load impedance 0 Ω - 300 Ω at UB> 10 V, 0 Ω - 500 Ω at UB> 15 V
