Nominal size, Laval nozzle 0.95 mm
Mounting position optional
Ejector characteristic High vacuum
Integrated function Electric ejector pulse valve
Electric on-off valve
Design T-shape
Symbol 00991493
Operating pressure 1.5 bar ... 8 bar
Max. vacuum 90 %
Duty cycle 100%
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation not possible
LABS (PWIS) conformity VDMA24364-B2-L
Media temperature 0 °C ... 50 °C
Degree of protection IP65
Ambient temperature 0 °C ... 50 °C
Electrical connection Plugs
Type of mounting Via female thread
Pneumatic connection, port 1 G1/8
Vacuum connection G1/8
Material housing Aluminium
